Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Maxim Integrated
Packaging Tube
RF Type Cellular, DCS, EDGE, PCS, UMTS, WLL
Frequency 1.7GHz ~ 2.2GHz
Number of Mixers 1
Gain 8.5dB
Noise Figure 9.5dB
Secondary Attributes Down Converter
Supply Current 230mA
Supply Voltage (V) 4.75V ~ 5.25V
Manufacturer Package 20-WQFN Exposed Pad
Supplier Device Package 20-TQFN-EP (5x5)
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 707670-MAX9993ETP
Series MAX series
Popularity Low
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MAX9993ETP CAD Model

Description

Maxim Integrated's MAX9993ETP High-Linearity, Low-Noise Downconversion Mixer

The MAX9993ETP from Maxim Integrated is a state-of-the-art downconversion mixer designed to provide exceptional performance in RF systems. This advanced component is a perfect fit for applications requiring high linearity, low noise, and a wide dynamic range. The MAX9993ETP is an ideal choice for demanding environments such as base stations, wireless infrastructure, and high-performance communication systems.

Key Features

  • High Linearity: The device offers excellent third-order intercept point (IIP3) performance, which minimizes distortion in complex RF environments and maintains signal integrity.
  • Low Noise Figure: With its low noise figure, the MAX9993ETP ensures a clean signal conversion, improving the overall signal-to-noise ratio (SNR) of the system.
  • Wide Frequency Range: The mixer operates over a broad frequency range, making it versatile for various applications and able to support multiple RF bands.
  • Integrated LO Buffer: The inclusion of an integrated local oscillator (LO) buffer simplifies design and reduces the number of external components required, saving space and cost.
  • Lead(Pb)-Free, RoHS Compliant: The MAX9993ETP is manufactured with environmental consciousness, adhering to RoHS standards and being lead-free.

Applications

  • Wireless Infrastructure
  • Base Stations for Mobile Communications
  • Point-to-Point Radios
  • RF Test Equipment
  • Satellite Communications

Technical Specifications

The MAX9993ETP offers a conversion gain of 8.9dB and an RF frequency range from 1700MHz to 2200MHz. Its local oscillator (LO) frequency spans from 1550MHz to 2150MHz, and it features an LO input drive level of 0dBm. The device is housed in a compact, 20-pin TQFN-EP (Exposed Pad) package, which aids in thermal management and allows for a smaller footprint on the PCB.

Maxim Integrated's commitment to quality and performance is evident in the MAX9993ETP mixer. This component is designed to deliver top-tier results in high-frequency applications where precision and reliability are paramount. Integrating the MAX9993ETP into your RF design will ensure a robust and efficient signal conversion process, enhancing the overall performance of your communication system.
