Products specifications

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Tube/Rail
Status Obsolete(EOL)
Type Class AB
Output Type 2-Channel (Stereo) with Stereo Headphones
Max Output Power x Channels @ Load 2W x 2 @ 4 Ohm; 100mW x 2 @ 16 Ohm
Supply Voltage - Operating 4.5 V to 5.5 V
Features Depop, Mute, Short-Circuit and Thermal Protection, Shutdown
Mounting SMD (SMT)
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 32-TQFN-EP (5x5)
Dimension 32-WFQFN Exposed Pad
Win Source Part Number 099887-MAX9789AETJ+
Ultra Librarian 3D Model Ultra Librarian MAX9789AETJ+ CAD Model

Description

Maxim Integrated MAX9789AETJ+ Audio Amplifier IC

The MAX9789AETJ+ from Maxim Integrated is a versatile and high-performance audio amplifier integrated circuit (IC) designed to deliver exceptional sound quality for a wide range of audio applications. This compact yet powerful IC integrates a mono speaker amplifier and a stereo headphone amplifier, making it an ideal solution for portable and space-constrained audio devices.

Key Features:

  • Integrated Audio Solution: The MAX9789AETJ+ combines a 2.2W mono speaker amplifier with a stereo headphone amplifier, providing an all-in-one audio amplification solution.
  • High Efficiency: Designed with Maxim's proprietary Class G architecture, it offers high efficiency, which is critical for battery-powered devices, helping to extend battery life.
  • Low EMI Emission: The IC is engineered to minimize electromagnetic interference (EMI), ensuring that it can be used in sensitive applications without causing disruptions.
  • Flexible Power Supply: It operates over a wide 2.7V to 5.5V supply voltage range, accommodating various power sources and system requirements.
  • Comprehensive Protection: The MAX9789AETJ+ includes built-in thermal overload protection, short-circuit protection, and a click-and-pop suppression feature to enhance the user experience.

Applications:

The MAX9789AETJ+ is perfectly suited for a variety of applications where high-quality audio amplification is required. These include:

  • Mobile phones
  • Portable media players
  • Notebook computers
  • Tablet devices
  • Portable gaming systems

Technical Specifications:

  • Output Power: 2.2W into 4Ω (Mono Speaker)
  • Headphone Amplifier Configuration: Stereo
  • THD+N: 0.02% (Typical)
  • Package/Case: 32-TQFN-EP
  • Operating Temperature Range: -40°C to +85°C

The MAX9789AETJ+ is available in a compact 32-TQFN-EP (Thin Quad Flat No Leads with Exposed Pad) package, which aids in thermal management and saves board space. Its combination of efficiency, performance, and integrated features make it a top choice for designers looking to enhance the audio performance of their products without sacrificing space or power efficiency.
