Maxim Integrated MAX775CSA+ Voltage Converter

The MAX775CSA+ is a versatile, high-efficiency, step-up DC-DC voltage converter from the renowned manufacturer Maxim Integrated. Designed to deliver a reliable power solution, this compact component is ideal for portable devices, where efficient power conversion and space constraints are critical considerations.

Key Features

• Adjustable Output Voltage: The MAX775CSA+ allows users to set the output voltage from 2V to 16.5V to accommodate a wide range of applications and power requirements.
• High Efficiency: With its high switching frequency and low quiescent current, this voltage converter operates with high efficiency, minimizing power loss and extending battery life in portable devices.
• Low Battery Detector: It includes a low battery detector that provides an early warning for battery replacement or charge, ensuring uninterrupted operation.
• Compact SMD Package: The device comes in a space-saving 8-pin SOIC package, making it suitable for high-density PCB layouts.
• Wide Input Voltage Range: It operates over a broad input voltage range of 2.7V to 11.5V, making it compatible with various power sources, including single-cell lithium-ion batteries.

Applications

The MAX775CSA+ is an excellent choice for a multitude of applications that require a compact and efficient voltage boost solution. These applications include but are not limited to:

• Portable Electronic Devices
• Battery-Powered Equipment
• Handheld Instruments
• Medical Devices
• Power Backup Systems

Technical Specifications

Technical specifications of the MAX775CSA+ include a shutdown current of under 10µA, a max duty cycle of 94%, and a switching frequency of 300kHz. Its thermal overload protection ensures the device operates within safe temperature limits, preventing damage from overheating.

Whether for consumer electronics, medical technology, or industrial applications, the MAX775CSA+ from Maxim Integrated is a reliable and efficient choice for step-up voltage conversion needs.
