Maxim Integrated MAX709LCSA+T Microprocessor Supervisory Circuit

The MAX709LCSA+T from Maxim Integrated is a high-quality microprocessor (µP) supervisory circuit designed to monitor power supplies and microprocessor activity in digital systems. It provides excellent circuit reliability and low cost by eliminating external components and adjustments when used in system applications.

This device performs a variety of functions to ensure that the digital system operates reliably under power-up, power-down, and brown-out conditions. The MAX709LCSA+T helps to prevent code execution errors in microprocessors and microcontrollers by monitoring the power supply voltage levels and providing a reset signal to the µP during out-of-tolerance conditions.

Key features of the MAX709LCSA+T include:

• Power Supply Monitoring: It ensures that the system's voltage levels are within acceptable ranges, and if not, it generates a reset signal to the µP. The reset signal remains active for a minimum of 140ms after the supply voltage exceeds the reset threshold, providing ample time for the µP to return to a stable state.
• Manual Reset Input: A manual reset input allows for a reset to be triggered with an external switch or logic signal, providing an additional layer of control for system resets.
• Watchdog Timer: The built-in watchdog timer keeps the µP from running away or becoming unresponsive by resetting it if it fails to stroke the watchdog within a preset timeout period.
• Compact SMT Package: The device is offered in a small 8-pin SOIC package, making it suitable for space-constrained applications.

The MAX709LCSA+T operates over a wide voltage range and has a low quiescent current, making it suitable for use in portable and battery-operated equipment. Its applications include computers, controllers, intelligent instruments, critical µP and µC power monitoring, and portable/battery-powered equipment.

With its robust feature set and reliable performance, the MAX709LCSA+T is an essential component for system designers seeking to enhance the operational stability and reliability of their digital systems.
