Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Tube/Rail
Status Active
Type Simple Reset/Power-On Reset
Number of Voltages Monitored 1
Output Push-Pull, Push-Pull
Reset Active High/Active Low
Reset Timeout 140 ms Minimum
Voltage - Threshold 4.65V
Temperature Range - Operating 0°C to 70°C (TA)
Mounting Through Hole
Case / Package 8-PDIP
Win Source Part Number 022091-MAX707CPA+
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MAX707CPA+ CAD Model

Description

Maxim Integrated MAX707CPA+ Microprocessor Supervisory Circuit

The MAX707CPA+ is a compact, highly reliable microprocessor (µP) supervisory circuit designed and manufactured by Maxim Integrated. This precision device is engineered to monitor power supplies and microprocessor activity in digital systems, ensuring proper system operation through reset and watchdog functions. The MAX707CPA+ is particularly suitable for use in computers, controllers, intelligent instruments, and critical µP-powered applications where dependable system stability is paramount.

Key Features:

  • Power Supply Monitoring: The MAX707CPA+ provides a precise monitoring function for +5V power supplies, ensuring that the system voltage remains within safe operating limits.
  • Manual Reset Input: A dedicated manual reset input allows for an external trigger to initiate a system reset, providing additional control and safety mechanisms for system operators.
  • Watchdog Timer: An integrated watchdog timer helps to prevent system failures due to software lock-up, requiring regular toggling by the µP within a preset timeout period to avoid an automatic system reset.
  • Reset Timeout: The device features an adjustable reset timeout, which can be set according to the specific needs of the application, allowing for a tailored system response.
  • Voltage Threshold Options: The MAX707CPA+ is available with several factory-set reset voltage thresholds, accommodating a range of power supply tolerances and system requirements.
  • Low Power Consumption: Designed for energy-efficient operation, the MAX707CPA+ consumes minimal power, making it ideal for battery-powered and portable applications.
  • Compact Packaging: Housed in an 8-pin DIP or SO package, the MAX707CPA+ saves valuable board space while offering robust functionality.

Applications:

  • Computers and Servers
  • Embedded Systems
  • Portable/Battery-Powered Devices
  • Intelligent Instruments
  • Industrial Controllers

The MAX707CPA+ from Maxim Integrated is an essential component for maintaining the integrity and reliability of digital systems. Its ability to closely monitor system parameters and initiate protective measures makes it a trusted solution for designers and engineers looking to enhance system resilience and prevent data loss due to power anomalies or software errors.
