The MAX705ESA, designed and manufactured by Maxim Integrated, is a compact, highly-reliable microprocessor (µP) supervisory circuit that provides essential monitoring functions for microprocessor systems. Its primary purpose is to safeguard system integrity during power-up, operation, and power-down.

Key Features

• Power Supply Monitoring: The device ensures that the µP is only operational with a stable power supply by monitoring the reset and power-fail functions. It can handle a supply voltage range from 4.5V to 5.5V, making it versatile for various applications.
• Manual Reset Capability: A manual reset input allows the user to initiate a system reset, providing additional control over system operation.
• Watchdog Timer: An on-board watchdog timer helps to detect and recover from system malfunctions.
• Battery Backup Switching: It includes a battery backup capability that automatically switches to the backup battery when the main power supply fails, ensuring continuous operation.
• Low Power Consumption: The MAX705ESA is designed for low power consumption, making it suitable for power-sensitive applications.
• Small Form Factor: Offered in an 8-pin SO package, it is compact and suitable for space-constrained applications.

Applications

This supervisory circuit is ideal for use in a wide range of applications, including:

• Computers and Controllers
• Intelligent Instruments
• Portable/Battery-Powered Equipment
• Embedded Systems

Technical Specifications

The MAX705ESA operates over a temperature range of -40°C to +85°C, ensuring reliable performance in various environmental conditions. It features a reset output stage with a push-pull configuration, which eliminates the need for an external pull-up resistor.

Quality and Reliability

Maxim Integrated is known for its commitment to quality and reliability, and the MAX705ESA is no exception. It is built to the highest standards and thoroughly tested to ensure it meets the rigorous demands of industrial and commercial applications.
