Products specifications

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 1/1
Duplex Half
Receiver Hysteresis 25mV
Data Rate 10Mbps
Supply Voltage - Operating 4.75 V to 5.25 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 021570-MAX3443EESA+T
Family Name MAX3443E
Introduction Date December 01, 1994
ECCN EAR99
Country of Origin Malaysia, Philippines, Thailand
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MAX3443EESA+T CAD Model

Description

Maxim Integrated MAX3443EESA+T RS-485/RS-422 Transceiver

The MAX3443EESA+T from Maxim Integrated is a high-performance, low-power transceiver for RS-485 and RS-422 communication, encapsulated in a compact 8-pin NSOIC package. This device is designed to facilitate robust, bidirectional serial communication in harsh industrial environments, with a focus on minimizing power consumption and maximizing data integrity.

Key Features

  • Electrical Specifications: The MAX3443EESA+T operates over a single 3.3V supply and is fully compliant with the EIA/TIA-485 and EIA/TIA-422 standards. It features a data rate of up to 10Mbps, making it suitable for high-speed applications.
  • Enhanced ESD Protection: It comes with enhanced Electrostatic Discharge (ESD) protection exceeding ±15kV using the Human Body Model (HBM), ensuring robustness and reliability in the field.
  • Low Power Operation: The device features a low-current shutdown mode and an ultra-low current standby mode, which significantly reduce the power consumption when the transceiver is not in active use.
  • Fail-Safe Receiver: The fail-safe receiver guarantees a logic-high receiver output when the receiver inputs are open or shorted, or when they are connected to a terminated transmission line with all drivers disabled.
  • Half-Duplex Communication: The transceiver supports half-duplex communication, allowing for bidirectional communication over a single pair of wires.
  • Thermal Shutdown: It also includes a thermal shutdown feature to protect the device from damage due to excessive power dissipation.

Applications

The MAX3443EESA+T is ideal for a variety of applications where reliable data transmission is required, including:

  • Industrial Control Systems
  • Building Automation
  • Networked Security Systems
  • Point of Sale (POS) Systems
  • Telecommunications Infrastructure

With its combination of high-speed operation, low power consumption, and robust protection features, the MAX3443EESA+T is an excellent choice for designers looking to implement efficient and reliable communication in their systems. Maxim Integrated's commitment to quality ensures that this transceiver will perform to the highest standards, making it a trusted component in any RS-485 or RS-422 communication network.
