Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Tube/Rail
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 3/5
Duplex Full
Receiver Hysteresis 500mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 28-SSOP
Win Source Part Number 003018-MAX3241ECAI+
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MAX3241ECAI+ CAD Model

Description

The MAX3241ECAI+ is a highly integrated serial communication component from Maxim Integrated, designed to facilitate robust and reliable data transmission in demanding environments. This component is a quintessential solution for applications requiring low-power operation and high data-rate communication with minimal external components.

Key Features:

  • Low Power Consumption: The MAX3241ECAI+ is designed for battery-powered applications, featuring a low-power shutdown mode that significantly reduces power usage when the device is not in active communication.
  • High Data Rates: Capable of supporting data rates up to 1Mbps, this device is well-suited for high-speed data transfer applications, providing efficient communication for complex systems.
  • Wide Supply Voltage Range: Operating from a 3.0V to 5.5V supply voltage, the MAX3241ECAI+ offers flexibility in power supply design, making it adaptable to various system architectures.
  • Electrostatic Discharge (ESD) Protection: With integrated ESD protection, the MAX3241ECAI+ ensures resilience against electrostatic discharges, safeguarding the device in industrial and commercial environments.
  • Integrated Charge Pump: The inclusion of an internal charge pump circuit eliminates the need for an external voltage converter, thus reducing the overall component count and board space.

Applications:

The MAX3241ECAI+ is a versatile component that finds use in a variety of applications. It's particularly well-suited for portable devices, such as PDAs and laptops, where power efficiency is critical. Additionally, it's used in industrial control systems, point-of-sale systems, and network equipment where high data-rate communication and robustness are required.

Technical Specifications:

  • Supply Voltage: 3.0V to 5.5V
  • Data Rate: Up to 1Mbps
  • Receiver Hysteresis: 300mV
  • Number of Drivers/Receivers: 3/5
  • Operating Temperature Range: -40°C to +85°C
  • Package: 28-SSOP

Overall, the MAX3241ECAI+ from Maxim Integrated is an excellent choice for designers looking for a reliable, high-performance serial communication interface that conserves power and reduces design complexity.
