Maxim Integrated MAX14998ETO+ High-Speed, Dual 2:1 Multiplexer

The Maxim Integrated MAX14998ETO+ is a high-performance, dual 2:1 multiplexer designed for precision signal routing in complex electronic systems. This versatile component is ideal for applications requiring high-speed data switching, such as USB 3.0/3.1, DisplayPort, HDMI, and PCI Express interfaces. Its exceptional signal integrity and low on-resistance make it a perfect choice for designers looking to maintain signal quality while switching between high-speed differential pairs.

Key Features

• High-Speed Performance: Engineered to handle data rates up to 10.3125Gbps, the MAX14998ETO+ is optimized for the latest high-speed serial interfaces.
• Dual 2:1 Multiplexer: The device includes two independent 2:1 multiplexer channels, allowing for flexible signal routing in a compact package.
• Low On-Resistance: Features a low on-resistance of typically 6Ω (max), which helps to preserve signal integrity and reduce insertion loss.
• Wide Bandwidth: Offers a wide -3dB bandwidth greater than 11.5GHz, ensuring minimal signal degradation during switching.
• Power Efficiency: With a single supply operation of +3.0V to +3.6V, the device is designed for low power consumption, making it suitable for power-sensitive applications.
• ESD Protection: Integrated ESD protection circuitry guards the device against electrostatic discharge events, enhancing system reliability.

Applications

• USB 3.0/3.1 Switching
• DisplayPort and HDMI Multiplexing
• PCI Express Lane Switching
• High-Speed Signal Routing
• Consumer Electronics
• Data Communication Equipment

The MAX14998ETO+ comes in a compact 42-TQFN-EP package, making it suitable for space-constrained applications. Its operational temperature range of -40°C to +85°C allows for deployment in a variety of environments. Maxim Integrated's commitment to quality ensures that the MAX14998ETO+ meets the rigorous demands of modern electronic systems, providing a reliable and efficient solution for high-speed signal switching.

Whether you are designing state-of-the-art consumer electronics or high-performance data communication systems, the Maxim Integrated MAX14998ETO+ offers the speed, reliability, and performance needed to deliver an optimal user experience.
