Introducing the DS32KHZ/DIP: A High-Precision Temperature-Compensated Crystal Oscillator

The DS32KHZ/DIP from Maxim Integrated is a compact, highly reliable, temperature-compensated crystal oscillator (TCXO) designed to provide a precise 32.768 kHz output for timekeeping applications. This precision device is housed in a DIP (Dual In-line Package) making it suitable for through-hole mounting on printed circuit boards, which is ideal for various electronic products requiring a stable time base.

Key Features

• High Stability: The DS32KHZ/DIP offers excellent frequency stability over a wide temperature range, ensuring accurate timekeeping in diverse operating conditions.
• Low Power Consumption: Designed with power-sensitive applications in mind, this TCXO consumes minimal power, making it ideal for battery-operated devices.
• Compact Design: The DIP packaging allows for easy integration into existing designs without the need for surface-mount technology (SMT) capabilities.
• Long-term Reliability: Maxim Integrated's commitment to quality means that the DS32KHZ/DIP is built to provide consistent performance over the product's lifespan.

Applications

The DS32KHZ/DIP is an excellent choice for a broad range of applications that require a stable and precise clock source. These include:

• Real-Time Clocks (RTCs)
• Portable Instrumentation
• Wearable Electronics
• Smart Meters
• Industrial Control Systems
• Automotive Electronics

Technical Specifications

The DS32KHZ/DIP operates at a nominal frequency of 32.768 kHz, which is the standard frequency used in quartz crystal oscillators for timekeeping. It is designed to be used in conjunction with Maxim's real-time clocks, including the popular DS1302 and DS1307 series. The device requires a minimal supply voltage, which can range from 2.7V to 5.5V, accommodating various system power requirements.

Maxim Integrated's DS32KHZ/DIP is not only a testament to the company's innovation in precision timekeeping but also to its dedication to providing solutions that meet the needs of modern electronic systems. With its blend of performance, reliability, and ease of integration, the DS32KHZ/DIP crystal oscillator is an essential component for any time-sensitive application.
