The DS1813R-5+T&R from Maxim Integrated is a highly reliable, precision microprocessor supervisory circuit designed to monitor the supply voltage of microprocessor (µP) systems. It provides a cost-effective solution for systems that require protection against power faults, ensuring that all operations are carried out safely and effectively.

Key Features

• Voltage Monitoring: This device actively monitors the VCC for undervoltage conditions during system power-up and operation. With a factory-trimmed reset threshold of 4.63V, it ensures that the µP and other critical components operate within safe voltage levels.
• Reset Timeout: The DS1813R-5+T&R generates a reset signal for a minimum of 350ms after VCC has risen above the reset threshold. This provides ample time for the system to stabilize before the processor begins operation.
• Temperature Range: It operates over a wide temperature range, making it suitable for various industrial applications. The device can function effectively in environments ranging from -40°C to +85°C.
• Form Factor: The component comes in a compact SOT-23 package, which is ideal for space-constrained applications without compromising performance and reliability.
• Power Supply: It supports a supply voltage range that typically spans from 1.2V to 5.5V, giving designers flexibility in various system configurations.

Applications

The DS1813R-5+T&R is an essential component for a wide array of applications, including:

• Computers and servers
• Embedded systems
• Portable/battery-powered equipment
• Industrial controllers
• Telecommunications equipment

Quality and Reliability

Maxim Integrated is known for their commitment to quality and reliability, and the DS1813R-5+T&R is no exception. It is designed to meet the stringent requirements of high-reliability environments, ensuring that your systems maintain their performance over time.

Ordering Information

The DS1813R-5+T&R is available in tape and reel packaging, facilitating easy integration into automated production lines. This packaging option is ideal for high-volume manufacturing and ensures safe and efficient handling of the components during assembly.
