The MDI6N60TH is a high-voltage N-channel MOSFET manufactured by MagnaChip Semiconductor. It is designed for use in various power switching applications. This MOSFET features low on-resistance and fast switching speed.

Applications

• Switching power supplies
• Motor control
• DC-DC converters
• Uninterruptible power supplies (UPS)
• Lighting ballasts

Features

• N-channel MOSFET
• High voltage (600V)
• Low on-resistance (RDS(on))
• Fast switching speed
• Avalanche ruggedness
• Isolated Package

Benefits

• Enables efficient power conversion with low on-resistance, reducing power losses.
• Suitable for high-voltage applications due to its 600V rating.
• Improves system efficiency with its fast switching speed.
• Provides robust performance in harsh environments.
• Simplified thermal management

Additional Details

The MDI6N60TH typically comes in a TO-220 or similar through-hole package. The gate threshold voltage is typically between 2V and 4V. The continuous drain current is typically around 6A. The on-resistance (RDS(on)) is typically in the range of a few ohms or less. The gate charge is a critical parameter that affects the switching speed. Lower gate charge means faster switching. A gate resistor is often used in series with the gate to damp oscillations and control the switching speed. Proper heatsinking is essential to dissipate the heat generated by the MOSFET during operation. The maximum junction temperature should not be exceeded. The avalanche ruggedness rating indicates the MOSFET's ability to withstand voltage spikes caused by inductive loads. It is important to design the circuit to prevent the MOSFET from entering avalanche mode during normal operation, but this feature provides a degree of robustness. This MOSFET is designed to be lead-free.
