MX29LV400CBXBI-70G Macronix MX29LV400CBXBI-70G real image
Same model may have multiple batches, images only for reference.
MX29LV400CBXBI-70G Macronix MX29LV400CBXBI-70G real image
MX29LV400CBXBI-70G Macronix MX29LV400CBXBI-70G real image
Same model may have multiple batches, images only for reference.

MX29LV400CBXBI-70G

Part No MX29LV400CBXBI-70G
Manufacturer Macronix
Catalog Memory
Description IC FLASH 4MBIT PARALLEL 48TFBGA
Datasheet
MX29LV400CBXBI-70G Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Memory - Memory
Mfr Macronix
Series MX29LV
Package Tray
Product Status Active
Programmable Not Verified
Memory Type Non-Volatile
Memory Format FLASH
Technology FLASH - NOR
Memory Size 4Mbit
Memory Organization 512K x 8
Memory Interface Parallel
Write Cycle Time - Word, Page 70ns
Access Time 70 ns
Voltage - Supply 2.7V ~ 3.6V
Temperature Range - Operating -40°C ~ 85°C (TA)
Mounting Type Surface Mount
Package / Case 48-TFBGA, CSPBGA
Supplier Device Package 48-TFBGA, CSP (6x8)
Base Product Number MX29LV400
Standard Package 480 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.32.0071
Win Source Part Number 646257-MX29LV400CBXBI-70G
Ultra Librarian 3D Model Ultra Librarian MX29LV400CBXBI-70G CAD Model

Description

The MX29LV400CBXBI-70G is a 4Mbit FLASH-NOR memory integrated circuit (IC) from Macronix.

  • Series: MX29LV
  • Package: 48-TFBGA, CSPBGA
  • Voltage Supply Range: 2.7V to 3.6V
  • Access Time: 70ns
  • Mounting Type: Surface Mount
  • Memory Format: FLASH
  • Write Cycle Time: 70ns
  • Memory Interface: Parallel
  • Product Status: Active
  • Memory Organization: 512K x 8
