Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Memory - Memory
Mfr Macronix
Series MXSMIO™
Package Tape & Reel
Product Status Active
Programmable Not Verified
Memory Type Non-Volatile
Memory Format FLASH
Technology FLASH - NOR
Memory Size 8Mbit
Memory Organization 1M x 8
Memory Interface SPI - Quad I/O
Clock Frequency 33 MHz
Write Cycle Time - Word, Page 100µs, 10ms
Voltage - Supply 1.65V ~ 3.6V
Temperature Range - Operating -40°C ~ 85°C (TA)
Mounting Type Surface Mount
Package / Case 8-UFDFN Exposed Pad
Supplier Device Package 8-USON (2x3)
Base Product Number MX25R8035
Standard Package 12,000 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.32.0071
Win Source Part Number 646104-MX25R8035FZUIL0
Ultra Librarian 3D Model Ultra Librarian MX25R8035FZUIL0 CAD Model

Description

The MX25R8035FZUIL0 is an 8Mbit FLASH - NOR memory integrated circuit (IC) from Macronix.

  • Type: Non-volatile memory
  • Voltage Supply: 1.65V to 3.6V
  • Organization: 1M x 8
  • Clock Frequency: 33 MHz
  • Write Cycle Time (Word): 100µs
  • Write Cycle Time (Page): 10ms
  • Memory Interface: SPI - Quad I/O
  • Package: Tape & reel
  • Package Quantity: 12,000 pcs
  • Operating Temperature: -40°C to 85°C
  • Status: Active
  • Manufacturer: Macronix
