LXML-PB01-0023 Lumileds
Same model may have multiple batches, images only for reference.

LXML-PB01-0023

Part No LXML-PB01-0023
Manufacturer Lumileds
Catalog LED Lighting - Color
Description BLUE
Datasheet
LXML-PB01-0023 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Optoelectronics - Color LED Lighting
Mfr Lumileds
Series LUXEON Rebel Color Line
Package Tape & Reel
Product Status Active
Color Blue
Wavelength 473nm
Current - Test 350mA
Voltage - Forward (Vf) (Typ) 2.95V
Lumens/Watt @ Current - Test 27 lm/W
Current - Max 1A
Luminous Flux @ Current/Temperature 28lm (Typ)
Temperature - Test 25°C
Viewing Angle 125°
Mounting Type Surface Mount
Package / Case 1812 (4532 Metric)
Supplier Device Package 1812
Size / Dimension 0.177" L x 0.120" W (4.49mm x 3.05mm)
Height - Seated (Max) 0.083" (2.10mm)
Base Product Number LXML
Standard Package 1,000 pcs
REACH Status REACH Unaffected
Win Source Part Number 627092-LXML-PB01-0023
Ultra Librarian 3D Model Ultra Librarian LXML-PB01-0023 CAD Model

Description

The LUXEON Rebel Color Line is a series of high-quality blue LEDs designed for color LED lighting applications manufactured by Lumileds.

  • Forward Voltage: 2.95V
  • Maximum Current: 1A
  • Viewing Angle: 125 degrees
  • Package: Compact surface mount, 0.177" L x 0.120" W (4.49mm x 3.05mm) with a seated height of 0.083" (2.10mm)
  • Luminous Flux: 28lm
  • Luminous Efficacy: 27lm/W
  • Product Status: Active
