SPHV24-01ETG-C Real Image SPHV24-01ETG-C real image15115 SPHV24-01ETG-C Real Image1 SPHV24-01ETG-C Real Image2
Same model may have multiple batches, images only for reference.
SPHV24-01ETG-C Real Image SPHV24-01ETG-C real image15115 SPHV24-01ETG-C Real Image1 SPHV24-01ETG-C Real Image2
SPHV24-01ETG-C Real Image SPHV24-01ETG-C real image15115 SPHV24-01ETG-C Real Image1 SPHV24-01ETG-C Real Image2
Same model may have multiple batches, images only for reference.

SPHV24-01ETG-C

Part No SPHV24-01ETG-C
Manufacturer Littelfuse Inc.
Catalog TVS - Diodes
Description TVS DIODE 24V 50V SOD882 / 200W Discrete Bidirectional TVS Diode
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Littelfuse Inc.
Packaging Reel
Type Zener
Bidirectional Channels 1
Voltage - Reverse Standoff (Typ) 24V (Maximum)
Voltage - Breakdown (Min) 26.7V
Voltage - Clamping (Maximum) at Ipp 50V
Current - Peak Pulse (10/1000μs) 3A (8/20μs)
Power - Peak Pulse 200W
Power Line Protection No
Applications Automotive
Capacitance at Frequency 17pF at 1MHz
Temperature Range - Operating -40°C ~ 125°C
Mounting Style SMD
Manufacturer Package SOD-882
Supplier Device Package SOD-882
Manufacturer Pack Quantity 10,000
MSL Level 1 (Unlimited)
Popularity High
Supply and Demand Status Sufficient
Win Source Part Number 800658-SPHV24-01ETG-C
Ultra Librarian 3D Model Ultra Librarian SPHV24-01ETG-C CAD Model

Description

The 800658-SPHV24-01ETG-C is a bidirectional Zener diode, designed for use in automotive applications.

  • Reverse Standoff Voltage: 24V
  • Breakdown Voltage: 26.7V
  • Peak Pulse Current: 3A (8/20μs)
  • Peak Pulse Power: 200W
  • Package: SOD-882
  • Operating Temperature: -40°C to 125°C
  • Capacitance @ Frequency: 17pF @ 1MHz
  • Voltage Clamping (Maximum) @ Ipp: 50V
