Same model may have multiple batches, images only for reference.

SMDJ7.0CA

Name: SMDJ7.0CA
Brand: Littelfuse Inc.
SKU: 669050
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SMDJ7.0CA
Manufacturer	Littelfuse Inc.
Catalog	TVS - Diodes
Description	TVS DIODE 7VWM 12VC DO214AB
Datasheet	SMDJ7.0CA Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr	Littelfuse Inc.
Series	SMDJ
Package	Tape & Reel
Product Status	Active
Type	Zener
Bidirectional Channels	1
Voltage - Reverse Standoff (Typ)	7V
Voltage - Breakdown (Min)	7.78V
Voltage - Clamping (Max) @ Ipp	12V
Current - Peak Pulse (10/1000µs)	250A
Power - Peak Pulse	3000W (3kW)
Power Line Protection	No
Applications	General Purpose
Temperature Range - Operating	-65°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	DO-214AB, SMC
Supplier Device Package	DO-214AB (SMCJ)
Standard Package	3,000 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.10.0080
California Prop 65	Warning Information
Win Source Part Number	669050-SMDJ7.0CA
Ultra Librarian 3D Model	Ultra Librarian SMDJ7.0CA CAD Model

Alternative Products

Description

The SMDJ7.0CA is a Zener-type transient voltage suppressor diode used for general-purpose circuit protection.

Series: SMDJ
Type: Zener
Package / Case: DO-214AB (SMC)
Voltage - Reverse Standoff (Typ): 7V
Voltage - Breakdown (Min): 7.78V
Voltage - Clamping (Max) @ Ipp: 12V
Power Line Protection: No
Power - Peak Pulse: 3000W (3kW)
Current - Peak Pulse (10/1000µs): 250A
Mounting Type: Surface Mount
Packaging: Tape & Reel (TR)
Operating Temperature: -65°C ~ 150°C (TJ)
Capacitance @ Frequency: -
Product Status: Active
Manufacturer: Littelfuse Inc.
