Same model may have multiple batches, images only for reference.

SMCJ8.0A

Name: SMCJ8.0A
Brand: Littelfuse Inc.
SKU: 328590
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SMCJ8.0A
Manufacturer	Littelfuse Inc.
Catalog	TVS - Diodes
Description	TVS Diode Single Uni-Dir 8V 1.5KW 2-Pin SMC T/R / TVS DIODE 8VWM 13.6VC SMC
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Manufacturer	Littelfuse Inc.
Standard Package	1
Category	Circuit Protection
Family	TVS - Diodes
Series	SMCJ
Packaging	Reel
Type	Zener
Unidirectional Channels	1
Voltage - Reverse Standoff (Typ)	8V
Voltage - Breakdown (Min)	8.89V
Voltage - Clamping (Max) @ Ipp	13.6V
Current - Peak Pulse (10/1000µs)	110.3A
Power - Peak Pulse	1500W (1.5kW)
Power Line Protection	No
Applications	General Purpose
Operating Temperature Range	-55°C ~ 150°C (TJ)
Mounting Style	SMD/SMT
Package	DO-214AB SMC
Manufacturer Device Package	DO-214AB (SMCJ)
Catalog	SMCJ Series
Win Source Part Number	064944-SMCJ8.0A
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	SMCJ8.0A
Introduction Date	May 12, 2005
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian SMCJ8.0A CAD Model

Alternative Products

Description

The SMCJ8.0A is a circuit protection electronic component manufactured by Littelfuse Inc.

Series: SMCJ series
Popularity: High popularity in the market
Voltage Breakdown: 8.89V
Power - Peak Pulse: 1500W
Description: An essential part of many electronic devices and is highly sought after by manufacturers
Compliance: Compliant with RoHS regulations and is halogen-free
