SMCJ10CA Real Image SMCJ10CA real image5609
Same model may have multiple batches, images only for reference.
SMCJ10CA Real Image SMCJ10CA real image5609
SMCJ10CA Real Image SMCJ10CA real image5609
Same model may have multiple batches, images only for reference.

SMCJ10CA

Part No SMCJ10CA
Manufacturer Littelfuse Inc.
Catalog TVS - Diodes
Description TVS DIODE 10VWM 17VC SMC
Datasheet
SMCJ10CA Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection
Family TVS - Diodes
Manufacturer Littelfuse Inc.
Series SMCJ
Packaging Reel(TR)
Type Zener
Bidirectional Channels 1
Voltage - Reverse Standoff (Typ) 10V
Voltage - Breakdown (Min) 11.1V
Voltage - Clamping (Max) @ Ipp 17V
Current - Peak Pulse (10/1000μs) 88.3A
Power - Peak Pulse 1500W (1.5kW)
Power Line Protection No
Applications General Purpose
Operating Temperature Range -55°C ~ 150°C (TJ)
Mounting Style SMD/SMT
Package DO-214AB, SMC
Manufacturer Device Package DO-214AB (SMCJ)
Win Source Part Number 029272-SMCJ10CA
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SMCJ10CA CAD Model

Description

The Littelfuse Inc. 029272-SMCJ10CA is a zener type TVS diode that is designed for general-purpose applications.

  • Channel Type: Unidirectional and Bidirectional
  • Voltage Reverse Standoff: 10V
  • Voltage Breakdown: 11.1V
  • Voltage Clamping @ Ipp: 17V
  • Peak Pulse Current: 88.3A
  • Peak Pulse Power: 1500W
  • Package: DO-214AB SMC
  • Mounting: SMD/SMT
  • Operating Temperature Range: -55°C to 150°C (TJ)
  • Supply and Demand Status: Balanced
