Same model may have multiple batches, images only for reference.

SMAJ6.5A

Name: SMAJ6.5A
Brand: Littelfuse Inc.
SKU: 327676
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SMAJ6.5A
Manufacturer	Littelfuse Inc.
Catalog	TVS - Diodes
Description	TVS DIODE 6.5VWM 11.2VC SMA
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Manufacturer	Littelfuse Inc.
Standard Package	1
Category	Circuit Protection
Family	TVS - Diodes
Series	SMAJ
Packaging	Reel
Type	Zener
Unidirectional Channels	1
Voltage - Reverse Standoff (Typ)	6.5V
Voltage - Breakdown (Min)	7.22V
Voltage - Clamping (Max) @ Ipp	11.2V
Current - Peak Pulse (10/1000µs)	35.7A
Power - Peak Pulse	400W
Power Line Protection	No
Applications	General Purpose
Operating Temperature Range	-55°C ~ 150°C (TJ)
Mounting Style	SMD/SMT
Package	DO-214AC SMA
Manufacturer Device Package	DO-214AC (SMA)
Catalog	SMAJ Series
Kits	SMAJ-A-KIT - KIT TVS DIODE 400W UNI-DIR SMA
Win Source Part Number	064804-SMAJ6.5A
Popularity	Medium
Supply and Demand Status	Balance
Package	Tape & Reel (TR);Cut Tape (CT)
Product Status	Active
Operating Temperature	-65°C ~ 150°C (TJ)
Grade	-
Mounting Type	Surface Mount
Package / Case	DO-214AC, SMA
Supplier Device Package	DO-214AC (SMA)
Package	Tape & Reel (TR)
Operating Temperature	-55°C ~ 150°C (TJ)
Power Line Protection	Yes
Operating Temperature	-55°C ~ 150°C
Supplier Device Package	DO-214AC (SMAJ)
Ultra Librarian 3D Model	Ultra Librarian SMAJ6.5A CAD Model

Alternative Products

Description

The Littelfuse SMAJ6.5A is a Zener diode designed for circuit protection.

Series: SMAJ
Package: DO-214AC SMA
Operating Temperature: -55°C to 150°C (TJ)
Application: General purpose
Voltage Rating (Reverse Standoff): 6.5V
Voltage Breakdown: 7.22V
Voltage Clamping @ Ipp: 11.2V
Peak Pulse Power: 400W
Channels: 1 unidirectional
Peak Pulse Current: 35.7A
Kit: SMAJ-A-KIT (includes 400W uni-directional TVS diode)
Packaging: Reel
Popularity: Medium
