P6SMB200A Littelfuse Inc. P6SMB200A Real Image P6SMB200A label picture
Same model may have multiple batches, images only for reference.
P6SMB200A Littelfuse Inc. P6SMB200A Real Image P6SMB200A label picture
P6SMB200A Littelfuse Inc. P6SMB200A Real Image P6SMB200A label picture
Same model may have multiple batches, images only for reference.

P6SMB200A

Part No P6SMB200A
Manufacturer Littelfuse Inc.
Catalog TVS - Diodes
Description TVS DIODE 171VWM 274VC SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Littelfuse Inc.
Standard Package 1
Category Circuit Protection
Family TVS - Diodes
Series P6SMB
Packaging Reel
Type Zener
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 171V
Voltage - Breakdown (Min) 190V
Voltage - Clamping (Max) @ Ipp 274V
Current - Peak Pulse (10/1000µs) 2.2A
Power - Peak Pulse 600W
Power Line Protection No
Applications General Purpose
Operating Temperature Range -55°C ~ 150°C (TJ)
Mounting Style SMD/SMT
Package DO-214AA SMB
Manufacturer Device Package DO-214AA (SMBJ)
Catalog P6SMB Series
Kits P6SMB-A-KIT - KIT TVS DIODE 600W UNI-DIR SMB
Win Source Part Number 045506-P6SMB200A
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Automotive, Computers & Computer Peripherals, Communications & Networking, Consumer Electronics, Lighting, Sensing & Instrumentation, Industrial
Ultra Librarian 3D Model Ultra Librarian P6SMB200A CAD Model

Description

The Littelfuse P6SMB200A is a Zener diode designed for general-purpose applications in the circuit protection category. It is a part of the P6SMB series and is mounted in a DO-214AA SMB package.

  • Voltage Reverse Standoff: 171V
  • Voltage Breakdown: 190V
  • Maximum Clamping Voltage: 274V @ Ipp
  • Peak Pulse Power: 600W
  • Current Peak Pulse: 2.2A (10/1000µs)
  • Unidirectional: Yes
  • Response Time: Slow
  • Applications: Automotive, Computers & Computer Peripherals, Communications & Networking, Consumer Electronics, Lighting, Sensing & Instrumentation, and Industrial applications
  • Packaging: Reel
  • Standard Package: 1
