P3500SCLRP Littelfuse Inc. P3500SCLRP label picture
Same model may have multiple batches, images only for reference.
P3500SCLRP Littelfuse Inc. P3500SCLRP label picture
P3500SCLRP Littelfuse Inc. P3500SCLRP label picture
Same model may have multiple batches, images only for reference.

P3500SCLRP

Part No P3500SCLRP
Manufacturer Littelfuse Inc.
Catalog TVS - Thyristors
Description Thyristor Surge Protection Devices 320V 35A 2-Pin DO-214AA T/R / SIDACTOR BI 320V 400A DO-214AA
Datasheet
P3500SCLRP Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Littelfuse Inc.
Packaging Reel - TR
Status Active
Voltage - Breakover 400V
Voltage - Off State 320V
Voltage - On State 4V
Current - Peak Pulse (8/20μs) 400A
Peak Pulse Current(Ippm) 100A
Current - Hold (Ih) 150mA
Number of Elements 1
Capacitance 65pF
Mounting SMD (SMT)
Dimension DO-214AA, SMB
Win Source Part Number 026262-P3500SCLRP
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name P3500SC
Introduction Date September 01, 2004
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian P3500SCLRP CAD Model

Description

The P3500SCLRP is a surface-mount TVS diode designed by Littelfuse Inc.

  • Application: Power supplies, motor control, and lighting.
  • Features: Excellent protection against transient voltage spikes and surges, low clamping voltage, and fast response time.
  • Standards: Designed to meet RoHS standards for environmental protection.
