LR4-1300SSF Real Image
Same model may have multiple batches, images only for reference.

LR4-1300SSF

Part No LR4-1300SSF
Manufacturer Littelfuse Inc.
Catalog PTC Resettable Fuses
Description POLYSWITCH PTC RESET 13A STRAP / PTC Resettable Fuse 13A(hold) 21.2A(trip) 20VDC 100A 4.5W 10s 0.0035Ohm SMD Solder Pad 66.5 X 10 X 1.3mm Bag
Datasheet
LR4-1300SSF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Littelfuse Inc.
Series PolySwitch, LR4
Packaging Bulk
Type Polymeric
Voltage - Max 20V
Current - Max 100A
Current - Hold (Ih) (Maximum) 13A
Current - Trip (It) 21.2A
Time to Trip 10s
Resistance - Initial (Ri) (Minimum) 3.5 mOhm
Resistance - Post Trip (R1) (Maximum) 9 mOhm
Operating Temperature Range -40°C ~ 85°C
Mounting User Defined
Package Strap
Dimension 2.520" L x 0.382" W (64.00mm x 9.70mm)
Approvals CSA, TUV, UL
Win Source Part Number 780080-LR4-1300SSF
Popularity Medium
Supply and Demand Status Balance
Family Name LR4
Introduction Date November 09, 2015
ECCN EAR99
Country of Origin China
Estimated EOL Date 2029
Ultra Librarian 3D Model Ultra Librarian LR4-1300SSF CAD Model

Description

The Littelfuse Inc. LR4-1300SSF is a polymeric, strap-type, circuit protection device.

  • Maximum Voltage: 20V
  • Maximum Current: 100A
  • Current-trip (It): 21.2A
  • Time to trip: 10s
  • Current-hold (Ih) (Maximum): 13A
  • Resistance-initial (Ri) (Minimum): 3.5 mOhm
  • Resistance-post trip (R1) (Maximum): 9 mOhm
  • Operating Temperature Range: -40°C ~ 85°C
  • Approvals: CSA, TUV, UL
  • Estimated EOL Date: 2029
