SPXV020.L

Part No SPXV020.L
Manufacturer Littelfuse Inc.
Catalog Electrical, Specialty Fuses
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection>Electrical, Specialty Fuses
Mfr Littelfuse Inc.
Series POWR-GARD® SPXV
Mounting Type Holder
Fuse Type Cartridge
Current Rating (Amps) 20A
Voltage Rating - DC 1.5 kV
Applications Solar (Photovoltaic)
Approval Agency CE, UR
Breaking Capacity @ Rated Voltage 15kA
Package / Case Cartridge, Non-Standard
Dimension 0.406" Dia x 3.333" L (10.30mm x 84.65mm)
Melting I2t 701
DC Cold Resistance 0.0085 Ohms
Other Names -SPXV020.L,SPXV 20A,SPXV 20
Standard Package 50
MSL Level 1 (Unlimited)
ECCN EAR99
Win Source Part Number 1302284-SPXV020.L
Ultra Librarian 3D Model Ultra Librarian SPXV020.L CAD Model

Description

The Littelfuse Inc. POWR-GARD® SPXV fuse is a cartridge type electrical specialty fuse that has a voltage rating of 1.5 kV and a current rating of 20A.

  • Voltage Rating: 1.5 kV
  • Current Rating: 20A
  • Breaking Capacity: 15kA
  • DC Cold Resistance: 0.0085 Ohms
  • Melting I2t: 701
  • Application: solar (photovoltaic) applications
  • Package: non-standard cartridge
  • Dimension: 0.406" Dia x 3.333" L (10.30mm x 84.65mm)
