1SMB20CAT3G

Name: 1SMB20CAT3G
Brand: Littelfuse Inc.
SKU: 416927
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	1SMB20CAT3G
Manufacturer	Littelfuse Inc.
Catalog	TVS - Diodes
Description	TVS Diode Single Bi-Dir 20V 600W Automotive 2-Pin SMB T/R / TVS DIODE 20VWM 32.4VC SMB
Datasheet	1SMB20CAT3G Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Circuit Protection
Manufacturer	Littelfuse Inc.
Packaging	Reel - TR
Type	Zener
Bidirectional Channels	1
STAND-OFF Voltage (Vwm)	20V
Minimum Breakdown Voltage	22.2V
Max Clamping Voltage	32.4V
Peak Pulse Current(Ippm)	18.5A
Power Dissipation - Pd	600W
Applications	Automotive
Capacitance @ Frequency	425pF @ 1MHz
Temperature Range - Operating	-65°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	SMB
Win Source Part Number	1002626-1SMB20CAT3G
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Application Field	Used in Communications & Networking, Automation & Process Control, Automotive, Power Management, Consumer Electronics, Computers & Computer Peripherals, Medical, Industrial
Family Name	1SMB20CA
ECCN	EAR99
Country of Origin	Malaysia
Halogen Free	Compliant
Estimated EOL Date	Obsolete / End of life
Ultra Librarian 3D Model	Ultra Librarian 1SMB20CAT3G CAD Model

Alternative Products

Description

The Littelfuse Inc. 1SMB20CAT3G is a bidirectional zener diode.

Package: SMB
Operating Temperature Range: -65°C to 150°C (TJ)
Stand-Off Voltage: 20V
Minimum Breakdown Voltage: 22.2V
Maximum Clamping Voltage: 32.4V
Peak Pulse Current: 18.5A
Power Dissipation: 600W
Capacitance: 425pF @ 1MHz
Common Applications: communications and networking, automation and process control, automotive, power management, consumer electronics, computers and computer peripherals, medical, and industrial applications
