MOC3023S-TA1 Real Image MOC3023S-TA1 real image3537
Same model may have multiple batches, images only for reference.
MOC3023S-TA1 Real Image MOC3023S-TA1 real image3537
MOC3023S-TA1 Real Image MOC3023S-TA1 real image3537
Same model may have multiple batches, images only for reference.

MOC3023S-TA1

Part No MOC3023S-TA1
Manufacturer Lite-On Inc.
Catalog Optoisolators - Triac, SCR Output
Description OPTOISOLATOR 5KV TRIAC 6SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Lite-On Inc.
Packaging Reel - TR
Status Active
Output Type Triac
Zero Crossing Circuit No
Number of Channels 1
Isolation Voltage 5000Vrms
Voltage - Off State 400V
Static dV/dt (Min) 1kV/μs
Current - LED Trigger (Ift) (Max) 5mA
Current - Hold (Ih) 250μA (Typ)
Forward Voltage 1.15V
Continuous forward current- Max 50mA
Temperature Range - Operating -40°C to 100°C
Mounting SMD (SMT)
Case / Package 6-SMD
Approvals CQC, CSA, TUV, UL, VDE
Win Source Part Number 100004-MOC3023S-TA1
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name MOC3023S-TA1
Introduction Date September 03, 2001
ECCN EAR99
Estimated EOL Date 2023
Quantity per package 1k pcs
Ultra Librarian 3D Model Ultra Librarian MOC3023S-TA1 CAD Model

Description

The Lite-On Inc. MOC3023S-TA1 is a high-quality optocoupler that is perfect for use in a wide range of applications.

  • Approvals: CQC, CSA, TUV, UL, and VDE
  • Output Type: Triac
  • Forward Voltage: 1.15V
  • Off-State Voltage: 400V
  • Isolation Voltage: 5000Vrms
  • LED Trigger Current: 5mA (Max)
  • Current Hold: 250μA
  • Packaging: Reel
  • Mounting Technology: Surface-mount
  • Operating Temperature: -40°C to 100°C
