Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Linear Technology
Packaging Tube
Type Hot Swap Controller, Monitor
Number of Channels 1
Internal Switch(s) No
Applications ATCA, MicroTCA
Programmable Features Auto Retry, Current Limit, Fault Timeout, Latched Fault, OVP, UVLO
Operating Supply Voltage 2.9 V ~ 26.5 V
Operating Temperature Range 0°C ~ 70°C
Operating Supply Current 1.6mA
Mounting SMD
Package 16-SSOP (0.154", 3.90mm Width)
Manufacturer Package 16-SSOP
Feature Pins FB, /FLT, IMON, ISET, OV, PG, SOURCE, TIMER, UV
Win Source Part Number 783942-LTC4218CGN#PBF
Popularity Medium
Supply and Demand Status Limited
Family Name LTC4218
Introduction Date January 21, 2008
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LTC4218CGN#PBF CAD Model

Description

The LTC4218CGN#PBF is a sophisticated hot swap controller from Linear Technology designed to enable safe board insertion and removal from a live backplane. This integrated circuit provides a controlled turn-on and offers protection features to ensure the electrical systems' integrity during hot plugging.

Key Features

  • Wide Operating Range: The device operates over a voltage range of 2.9V to 26.5V, making it versatile for various applications.
  • Adjustable Current Limit: Users can set the overcurrent limit threshold as per their system requirements, which helps in protecting against excessive current draw that could damage the system components.
  • Overcurrent and Overvoltage Protection: The LTC4218CGN#PBF is equipped with features to protect against overcurrent and overvoltage conditions, ensuring the safety and longevity of the electronic components.
  • Power Good Output: This feature provides a signal indicating that the output voltage is within a specified range, which is essential for reliable system operation.
  • Automatic Retry or Latch Off: On fault detection, the device can be configured to either attempt a restart automatically or latch off, depending on the desired system response.
  • SO-8 Packaging: The compact SO-8 package allows for efficient use of board space, which is crucial for high-density electronic designs.

Applications

The LTC4218CGN#PBF is ideal for a range of applications where controlled power management is essential. It is commonly used in:

  • RAID Systems
  • Servers
  • Network Routers and Switches
  • Industrial Systems
  • Telecommunications Equipment

Conclusion

With its robust feature set and protection mechanisms, the LTC4218CGN#PBF from Linear Technology stands out as a reliable solution for managing hot swap events. It ensures that electronic systems can be safely maintained and upgraded without the need to power down the entire system, thus minimizing downtime and maintaining operational efficiency.
