Products specifications

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Output Type Transistor Driver
Purpose Step-Up, Step-Up/Step-Down
Topology Boost, Flyback, SEPIC
Number of Outputs 1
Output Phases 1
Supply Voltage - Operating 5.5 V to 100 V
Frequency - Switching 100kHz to 1MHz
Synchronous Rectifier No
Clock Sync Yes
Control Features Enable, Frequency Control, Soft Start
Temperature Range - Operating -40°C to 125°C (TJ)
Case / Package 10-MSOP-EP
Win Source Part Number 123864-LT3758EMSE#TRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LT3758EMSE#TRPBF CAD Model

Description

Product Overview

The LT3758EMSE#TRPBF is a versatile high voltage boost, flyback, SEPIC and inverting power DC/DC controller that drives an N-channel power MOSFET and can produce a stable output from a wide range of input voltages. Manufactured by Linear Technology, now part of Analog Devices, this component is designed to cater to a variety of applications, including telecom, industrial, automotive, and medical systems.

Key Features

  • Wide Input Voltage Range: The LT3758EMSE#TRPBF operates from an input voltage range of 2.9V to 40V, making it suitable for applications with varying power supply conditions.
  • Adjustable Switching Frequency: With a programmable frequency range from 100kHz to 1MHz, designers can optimize the component for efficiency or component size.
  • High Boost Ratios: Capable of very high boost ratios, the LT3758EMSE#TRPBF is ideal for applications requiring a high step-up ratio, such as driving LEDs in series.
  • Robust Protection Features: It includes under-voltage lockout, thermal shutdown, and frequency foldback to ensure reliable operation under fault conditions.
  • Multiple Topologies: The flexibility to be used in boost, flyback, SEPIC, or inverting converter topologies makes this controller highly adaptable to specific design requirements.

Applications

  • Telecom Power Supplies
  • Automotive and Industrial Power Systems
  • Medical Diagnostic Equipment
  • Portable Electronic Devices
  • LED Drivers
  • Power Over Ethernet (PoE) Systems

Packaging and Quality

The LT3758EMSE#TRPBF is packaged in a compact 16-lead MSOP (Medium Small Outline Package) with an exposed pad for enhanced thermal performance. This product is also available in a tape and reel format, denoted by the 'TRPBF' suffix, which is suitable for automated high-volume production environments. Linear Technology ensures high quality and reliability, making this controller a trusted choice for critical applications.

Conclusion

With its flexible input voltage range, high boost capability, and support for multiple topologies, the LT3758EMSE#TRPBF is a powerful solution for designers looking to create efficient, reliable, and compact power supply systems. Its advanced protection features and high switching frequency options further enhance its suitability for a wide array of demanding applications.
