The Leadtrend LD7538RGL is a current-mode PWM controller IC specifically designed for offline flyback converter applications. It integrates functions such as leading-edge blanking, cycle-by-cycle current limiting, and over-temperature protection. This device is suitable for applications demanding high efficiency, low standby power consumption, and robust protection features.

Applications:

• AC/DC Adapters
• Battery Chargers
• Standby Power Supplies
• LED Lighting Power Supplies

Features:

• Current-Mode PWM Control
• Leading-Edge Blanking
• Cycle-by-Cycle Current Limiting
• Over-Temperature Protection (OTP)
• Under-Voltage Lockout (UVLO)
• Low Start-up Current
• Internal Slope Compensation

Benefits:

• High Efficiency: Designed for optimal efficiency in flyback converter applications, reducing energy waste and heat dissipation.
• Robust Protection: Comprehensive protection features, including current limiting and over-temperature protection, enhance system reliability and prevent component damage.
• Simplified Design: Reduced external component count simplifies power supply design and lowers overall system cost.
• Low Standby Power: Minimizes power consumption in standby mode, meeting stringent energy efficiency requirements.
• Stable Operation: Built-in slope compensation ensures stability over a wide range of operating conditions.

The LD7538RGL comes in a SOT-26 package. It operates across a broad input voltage range and is engineered for minimal standby power usage. The component suits various power supply implementations where heightened efficiency and reliability are crucial.
