The LCMXO1200C-3MN132C is a Field-Programmable Gate Array (FPGA) from Lattice Semiconductor Corporation's MachXO family. These FPGAs are designed for low-density logic applications, offering a balance of low power consumption, small size, and sufficient performance for a variety of control and interface functions. The 'C' designation often indicates a commercial temperature range. The -3 indicates the speed grade. The MN132C refers to the package and temperature range.

Applications

• System Glue Logic
• Interface bridging
• Power supply sequencing
• Display control
• I/O expansion

Features

• 1200 LUTs (Look-Up Tables)
• Low power consumption
• Embedded memory blocks
• sysIO interface with flexible I/O support
• On-chip oscillator

Benefits

• Reduced system cost through integration of multiple functions
• Extended battery life in portable devices due to low power operation
• Increased design flexibility
• Fast prototyping and time-to-market
• Simplified board layout due to small package size

Technical Specifications

The LCMXO1200C-3MN132C operates with a core voltage typically at 1.2V or 2.5V depending on the exact configuration and speed grade. It features approximately 1200 LUTs, offering a moderate level of programmable logic. The device includes embedded memory, useful for implementing small data buffers or state machines. The I/O pins are highly flexible and can support a variety of interface standards. The on-chip oscillator simplifies clocking and reduces the need for external components. The MN132C package is a 132-pin PQFP (Plastic Quad Flat Pack) or similar, offering a balance of size and ease of use for PCB assembly. It is designed for operation within a commercial temperature range. Programming is typically done via JTAG.

In summary, the LCMXO1200C-3MN132C is a versatile and efficient FPGA suitable for a wide range of low-density logic applications. Its low power consumption, flexible I/O, and integrated features make it a popular choice for system glue logic, interface bridging, and other control functions. The MachXO family provides designers with a cost-effective and easy-to-use solution for implementing custom logic circuits.
