GAL22V10D-25LPNI label picture GAL22V10D-25LPNI real image
GAL22V10D-25LPNI label picture GAL22V10D-25LPNI real image
Same model may have multiple batches, images only for reference.

GAL22V10D-25LPNI

Part No GAL22V10D-25LPNI
Manufacturer Lattice Semiconductor Corporation
Catalog Embedded - CPLDs (Complex Programmable Logic Devices)
Description IC CPLD 10MC 25NS 24DIP
Datasheet
GAL22V10D-25LPNI Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Lattice Semiconductor Corporation
Packaging Tube/Rail
Status Obsolete(EOL)
Programmable Type EE PLD
Delay Time tpd(1) Max 25.0ns
Voltage Supply - Internal 4.5 V to 5.5 V
Number of Macrocells 10
Temperature Range - Operating -40°C to 85°C (TA)
Mounting Through Hole
Case / Package 24-PDIP
Win Source Part Number 1040785-GAL22V10D-25LPNI
Family Name GAL22V10D
Introduction Date August 22, 2008
ECCN EAR99
Country of Origin Indonesia, Philippines
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian GAL22V10D-25LPNI CAD Model

Description

The 1040785-GAL22V10D-25LPNI from Lattice Semiconductor Corporation is an EE PLD programmable integrated circuit with 10 macrocells.

  • Type: EE PLD
  • Number of Macrocells: 10
  • Number of I/O: Not specified
  • Delay Time tpd(1) max: 25.0ns
  • Voltage Supply Range: 4.5 V to 5.5 V
  • Case/Package: 24-PDIP
  • Status: Obsolete (EOL)
  • Temperature Range: -40°C to 85°C (TA)
  • Mounting Type: Through Hole
  • Packaging: Tube/Rail
  • Popularity: High
  • Supply and Demand Status: In Balance
