The KPT-1608SURWL-TW is a surface-mount LED manufactured by Kingbright Corporation. This LED is designed to provide high-intensity red light emission, making it suitable for various indicator and display applications. Its compact size and efficient performance make it a popular choice for modern electronic devices.

Applications:

• Backlighting in LCDs
• Indicator lights in electronic devices
• Automotive lighting
• Status indicators
• Consumer electronics displays

Features:

• High Luminous Intensity: Provides a bright and clear red light output, ensuring visibility in various lighting conditions.
• Compact Size: The 1.6 x 0.8 mm (1608) package allows for dense placement on circuit boards, saving space.
• Surface Mount Technology (SMT): Designed for automated assembly processes, reducing manufacturing time and costs.
• Wide Viewing Angle: Offers a wide viewing angle, ensuring the light is visible from multiple directions.
• Low Power Consumption: Operates efficiently, minimizing power usage and extending battery life in portable devices.

Benefits:

• Improved Visibility: The high luminous intensity ensures clear visibility, enhancing user experience.
• Space-Saving Design: The compact size enables integration into small and densely populated electronic devices.
• Cost-Effective Manufacturing: The SMT design simplifies assembly, reducing manufacturing costs.
• Enhanced Reliability: Built with high-quality materials and manufacturing processes, ensuring long-term reliability.
• Energy Efficiency: Low power consumption contributes to energy savings and extended battery life.

Additional Details:

The KPT-1608SURWL-TW LED is designed for reflow soldering, a common SMT assembly technique. It is also RoHS compliant, meaning it adheres to environmental standards by avoiding hazardous substances.

Technical Specifications (Typical Values):

• Wavelength: 630-635 nm (Red)
• Luminous Intensity: Varies based on drive current. Consult datasheet.
• Forward Voltage: 1.85V typical
• Viewing Angle: 150 degrees
• Package: 1608 (1.6 x 0.8 mm)

The “SURWL” portion of the part number indicates “Surface Mount Red Water Clear Lens.” The “TW” suffix may relate to tape and reel packaging.
