Same model may have multiple batches, images only for reference.
B45196H3335M109 Real Image
Same model may have multiple batches, images only for reference.

B45196H3335M109

Part No B45196H3335M109
Manufacturer Kemet
Catalog Ceramic Capacitors
Description Cap Tant 3.3UF 16V 20% 1206
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Capacitance 3.3 µF
Mounting SMD (SMT)
Case / Package 1206
Case Code (Imperial) 1206
Case / Package 3216
Depth 1.6 mm
Dissipation Factor 6 %
ESR (Equivalent Series Resistance) 5 Ω
Height 1.8 mm
Lead Free Yes
Leakage Current 500 nA
Length 3.2 mm
Maximum Operating Temperature 125 °C
Min Operating Temperature -55 °C
Packaging Tape and Reel
Polarity Polar
RoHS Compliant
Termination SMD/SMT
Tolerance 20 %
Voltage Rating 16 V
Voltage Rating (DC) 16 V
Width 1.6 mm
Win Source Part Number 1000086-B45196H3335M109
Categories Ceramic Capacitors
Manufacturer Kemet
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian B45196H3335M109 CAD Model

Description

The B45196H3335M109 is a 3.3μF 16V polarized ceramic capacitor that is manufactured by Kemet.

  • Capacitance: 3.3μF
  • Voltage: 16V
  • Polarized: Yes
  • Capacitance Tolerance: 20%
  • ESR: 5Ω
  • Leakage Current: 500nA
  • Dissipation Factor: 6%
  • Case/Package: 1206 or 3216
  • Height: 1.8mm
  • Width: 1.6mm
  • Length: 3.2mm
  • Temperature Range: -55°C to 125°C
  • Lead-Free: Yes
  • RoHS: Compliant
