The S10B-PHDSS(LF)(SN)(P) is a 10-position crimp style connector housing from JST's PH series. This connector housing is designed to be used with crimp contacts to create a reliable wire-to-board connection. It is commonly used in a variety of electronic devices and equipment.

Applications:

• Consumer electronics (e.g., televisions, audio equipment)
• Office equipment (e.g., printers, scanners)
• Industrial equipment (e.g., control panels, machinery)
• Medical devices (e.g., patient monitoring systems)
• Automotive electronics (e.g., dashboard controls)

Features:

• 10 positions for connecting multiple wires
• PH series design for compact size and reliable performance
• Crimp style connection for secure wire termination
• Polarization feature to prevent mis-mating
• RoHS compliant (LF = Lead-Free)
• Tin plating (SN) for corrosion resistance and solderability
• Packaging code (P)

Benefits:

• Provides a reliable and secure connection between wires and a circuit board.
• Saves space due to its compact design.
• Ensures correct mating through polarization features.
• Meets environmental regulations due to its RoHS compliance.
• Offers corrosion resistance and improved solderability due to the tin plating.
• Facilitates efficient assembly and manufacturing.

Additional Details:

The S10B-PHDSS(LF)(SN)(P) connector housing requires compatible crimp contacts to terminate the wires. The appropriate crimping tool should be used to ensure a proper and reliable connection. The housing is made of a durable plastic material that provides insulation and protection for the contacts.

Key specifications include:

• Number of Positions: 10
• Series: PH
• Pitch: 2.0 mm (typical for PH series)
• Material: Typically Nylon or similar plastic
• Plating: Tin (SN)
• Flammability Rating: Refer to datasheet (typically UL94V-0)

The S10B-PHDSS(LF)(SN)(P) is a robust and versatile connector housing suitable for a wide range of wire-to-board connection applications.
