JN2AS10ML1-R JAE Electronics – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

JN2AS10ML1-R

Part No JN2AS10ML1-R
Manufacturer JAE Electronics
Catalog Circular Connectors - Assemblies
Description CONN RCPT MALE 10POS SOLDER CUP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Connector Type Receptacle, Male Pins
Number of Positions 10
Shell Size - Insert S
Mounting Type Panel Mount
Mounting Feature Flange
Termination Solder Cup
Fastening Type Push-Twist
Orientation N (Normal)
Primary Material Metal
Shell Material Zinc Alloy
Shell Finish Zinc
Contact Finish - Mating Gold
Color Black
Current Rating (Amps) 3A
Voltage Rating 200VAC
Cable Opening 0.472" (12.00mm)
Temperature Range - Operating -20°C ~ 100°C
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1620453-JN2AS10ML1-R
Ultra Librarian 3D Model Ultra Librarian JN2AS10ML1-R CAD Model
