IXXH30N60B3D1

Name: IXXH30N60B3D1
Brand: IXYS
SKU: 812059
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IXXH30N60B3D1
Manufacturer	IXYS
Catalog	IGBTs - Single
Description	IGBT 600V 60A 270W TO247 / XPTTM 600V IGBT GenX3TM w/ Diode
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Manufacturer	IXYS
Packaging	Tube
IGBT Type	PT
Voltage - Collector Emitter Breakdown (Maximum)	600V
Current - Collector (Ic) (Maximum)	60A
Current - Collector Pulsed (Icm)	115A
Vce(on) (Maximum) at Vge, Ic	1.85V at 15V, 24A
Power - Max	270W
Switching Energy	550μJ (on), 500μJ (off)
Input Type	Standard
Gate Charge	39nC
Td (on/off) at 25°C	23ns/97ns
Test Condition	400V, 24A, 10Ohm, 15V
Reverse Recovery Time (trr)	25ns
Temperature Range - Operating	-55°C ~ 175°C
Mounting Style	Through Hole
Manufacturer Package	TO-247-3
Supplier Device Package	TO-247 (IXXH)
Manufacturer Pack Quantity	30
MSL Level	1 (Unlimited)
Popularity	Low
Supply and Demand Status	Limited
Win Source Part Number	812062-IXXH30N60B3D1
Ultra Librarian 3D Model	Ultra Librarian IXXH30N60B3D1 CAD Model

Description

The IXXH30N60B3D1 is a PT IGBT manufactured by IXYS Integrated Circuits Division.

Package: TO-247
Maximum Power Dissipation: 270W
Maximum Collector Current: 60A
Collector-Emitter Saturation Voltage: 1.85V @ 15V, 24A
Reverse Recovery Time: 25ns
Gate Charge: 39nC
