Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Max) 600 V
Current - Average Rectified (Io) 20 A
Voltage - Forward (Vf) (Max) @ If 2.13 V @ 11 A
Current - Reverse Leakage @ Vr 60 µA @ 600 V
Temperature Range - Operating -55°C ~ 175°C (TJ)
Mounting Type Through Hole
Case / Package i4-Pac™-5
Supplier Device Package ISOPLUS i4-PAC™
Package Tube
Supply and Demand Status Shortage
Win Source Part Number 1491059-FBE22-06N1
Ultra Librarian 3D Model Ultra Librarian FBE22-06N1 CAD Model
