DSEP29-12A Real Image DSEP29-12A real image17944 DSEP29-12A real image17945
Same model may have multiple batches, images only for reference.
DSEP29-12A Real Image DSEP29-12A real image17944 DSEP29-12A real image17945
DSEP29-12A Real Image DSEP29-12A real image17944 DSEP29-12A real image17945
Same model may have multiple batches, images only for reference.

DSEP29-12A

Part No DSEP29-12A
Manufacturer IXYS
Catalog Diodes, Rectifiers - Single
Description HiPerFRED Epitaxial Diode with soft recovery
Datasheet
DSEP29-12A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer IXYS
Series HiPerFRED
Packaging Tube
Diode Type Standard
Voltage - DC Reverse (Vr) (Maximum) 1200V
Current - Average Rectified (Io) 30A
Voltage - Forward (Vf) (Maximum) @ If 2.75V @ 30A
Speed Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 40ns
Current - Reverse Leakage @ Vr 250μA @ 1200V
Mounting Style Through Hole
Package TO-220-2
Manufacturer Package TO-220AC
Operating Temperature - Junction -55°C ~ 175°C
Win Source Part Number 1169834-DSEP29-12A
Manufacturer Homepage www.ixys.com
Popularity Medium
Supply and Demand Status Limited
Family Name DSEP29-12A
Introduction Date October 30, 2000
ECCN EAR99
Halogen Free Unknown
Estimated EOL Date 2023
Ultra Librarian 3D Model Ultra Librarian DSEP29-12A CAD Model

Description

The DSEP29-12A is a fast recovery diode manufactured by IXYS.

  • Type: Fast Recovery Diode
  • Manufacturer: IXYS
  • Average Rectified Current: 30A
  • Reverse Recovery Time: 40ns
  • Maximum Forward Voltage: 2.75V @ 30A
  • Maximum Reverse Voltage: 1200V
  • Operating Temperature: -55°C to 175°C
  • Package: TO-220-2
  • Applications: Ideal for power supplies, motor control, and lighting systems.
