DSEI2X61-12B Real Image DSEI2X61-12B Real Image
Same model may have multiple batches, images only for reference.
DSEI2X61-12B Real Image DSEI2X61-12B Real Image
DSEI2X61-12B Real Image DSEI2X61-12B Real Image
Same model may have multiple batches, images only for reference.

DSEI2X61-12B

Part No DSEI2X61-12B
Manufacturer IXYS
Catalog Diodes, Rectifiers - Arrays
Description Fast Recovery Epitaxial Diode (FRED)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer IXYS
Series FRED
Packaging Tube
Diode Configuration 2 Independent
Diode Type Standard
Voltage - DC Reverse (Vr) (Maximum) 1200V
Current - Average Rectified (Io) (per Diode) 52A
Voltage - Forward (Vf) (Maximum) @ If 2.5V @ 60A
Speed Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 60ns
Current - Reverse Leakage @ Vr 2.2mA @ 1200V
Mounting Chassis Mount
Package SOT-227-4, miniBLOC
Manufacturer Package SOT-227B
Win Source Part Number 1169825-DSEI2X61-12B
Manufacturer Homepage www.ixys.com
Popularity Medium
Supply and Demand Status Limited
Family Name DSEI2x61-12B
Introduction Date October 22, 2000
ECCN EAR99
Country of Origin Republic of Korea
Halogen Free Unknown
Estimated EOL Date 2023
Ultra Librarian 3D Model Ultra Librarian DSEI2X61-12B CAD Model

Description

The IXYS DSEI2X61-12B is a fast recovery diode with a reverse recovery time of 60ns.

  • Reverse Recovery Time: 60ns
  • Maximum Forward Voltage: 2.5V @ 60A
  • Maximum DC Reverse Voltage: 1200V
  • Package: SOT-227-4 miniBLOC
  • Mounting: Chassis
  • Current Rating Per Diode: 52A
  • Popularity: Popular
  • Supply and Demand Status: Limited
