Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Relays - Solid State Relays
Mfr IXYS
Series CPC, OptoMOS®
Package Tube
Product Status Active
Mounting Type Surface Mount
Circuit SPST-NO (1 Form A)
Output Type AC, DC
Voltage - Input 1.2VDC
Voltage - Load 0 V ~ 60 V
Load Current 100 mA
On-State Resistance (Max) 16 Ohms
Termination Style Gull Wing
Package / Case 4-SOP (0.150", 3.81mm)
Supplier Device Package 4-SOP
Base Product Number CPC1017
Standard Package 100 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.41.0030
California Prop 65 Warning Information
Win Source Part Number 580103-CPC1017N
Ultra Librarian 3D Model Ultra Librarian CPC1017N CAD Model

Description

The 580103-CPC1017N is a solid-state relay from the CPC, OptoMOS® series.

  • Circuit: SPST-NO (1 Form A)
  • On-State Resistance (Max): 16 Ohms
  • Load Current: 100mA
  • Load Voltage: 0V to 60V
  • Voltage Input: 1.2VDC
  • Output Type: AC/DC
  • Mounting Type: Surface Mount
  • Package: 4-SOP
  • Packaging: Tube
  • Standard Package Quantity: 100 pcs
  • Status: Active
  • Manufacturer: IXYS
