TLP521-4 Isocom Components 2004 LTD
Same model may have multiple batches, images only for reference.

TLP521-4

Part No TLP521-4
Manufacturer Isocom Components 2004 LTD
Catalog Optoisolators - Transistor, Photovoltaic Output
Description Optoisolator Transistor Output 5300Vrms 2 Channel 8-DIP
Datasheet
TLP521-4 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Isolators
Family Optoisolators - Transistor, Photovoltaic Output
Manufacturer Isocom Components 2004 LTD
Packaging Tube
Part Status Active
Number of Channels 2
Voltage - Isolation 5300Vrms
Current Transfer Ratio (Min) 100% @ 5mA
Current Transfer Ratio (Max) 600% @ 5mA
Rise / Fall Time (Typ) 4μs, 3μs
Input Type DC
Output Type Transistor
Voltage - Output (Max) 55V
Voltage - Forward (Vf) (Typ) 1.15V
Current - DC Forward (If) (Max) 50mA
Vce Saturation (Max) 400mV
Operating Temperature Range -30°C ~ 100°C
Mounting Style Through Hole
Package 8-DIP (0.300", 7.62mm)
Manufacturer Device Package 8-DIP
Win Source Part Number 218257-TLP521-4
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TLP521-4 CAD Model

Description

The Isocom Components 2004 LTD 218257-TLP521-4 is a Transistor Output Optoisolator that comes in an 8-DIP (0.300", 7.62mm) package.

  • Input Type: DC
  • Maximum DC Forward Current: 50mA
  • Forward Voltage: 1.15V
  • Voltage - Isolation: 5300Vrms
  • Current Transfer Ratio (Min): 100% @ 5mA
  • Output type: transistor
  • Maximum Voltage Output: 55V
  • Vce Saturation (Max): 400mV
  • Rise / Fall Time (Typ): 4μs, 3μs
  • Current Transfer Ratio (Max): 600% @ 5mA
  • Operating Temperature Range: -30°C ~ 100°C
  • Supply and demand status: balanced.
