X95840WV20IZ-2.7 Real Image X95840WV20IZ-2.7 Real Image
Same model may have multiple batches, images only for reference.
X95840WV20IZ-2.7 Real Image X95840WV20IZ-2.7 Real Image
X95840WV20IZ-2.7 Real Image X95840WV20IZ-2.7 Real Image
Same model may have multiple batches, images only for reference.

X95840WV20IZ-2.7

Part No X95840WV20IZ-2.7
Manufacturer Intersil
Catalog Data Acquisition - Digital Potentiometers
Description IC XDCP QUAD 256TAP 10K 20-TSSOP
Datasheet
X95840WV20IZ-2.7 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Intersil
Packaging Tube/Rail
Status Active
Taper Linear
Configuration Potentiometer
Number of Circuits 4
Number of Taps 256
Resistance (Ohms) 10k
Supply Voltage - Operating 2.7 V to 5.5 V
Features Selectable Address
Tolerance ±20%
Temperature Coefficient (Typ) ±45 ppm/°C
Resistance - Wiper (Ohms) (Typ) 70
Temperature Range - Operating -40°C to 85°C
Case / Package 20-TSSOP
Win Source Part Number 036569-X95840WV20IZ-2.7
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian X95840WV20IZ-2.7 CAD Model

Description

The Intersil X95840WV20IZ-2.7 is a potentiometer with selectable address and 256 taps.

  • Taper: Linear
  • Resistance: 10k ohms
  • Tolerance: ±20%
  • Operating Voltage Range: 2.7V to 5.5V
  • Operating Temperature Range: -40°C to 85°C
  • Supply and Demand Status: Limited
  • Package: 20-TSSOP
