Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Intersil
Packaging Tube/Rail
Status Active
Driven Configuration Half-Bridge
Channel Type Independent
Number of Drivers 4
Gate Type N-Channel MOSFET
Supply Voltage - Operating 8.5 V to 15 V
Logic Voltage - VIL, VIH 1V, 2.5V
Current - Peak Output (Source, Sink) 1A, 1A
Input Type Inverting, Non-Inverting
High Side Voltage - Max (Bootstrap) 70V
Rise and Fall Time 9ns, 9ns
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 16-SOIC
Win Source Part Number 070114-ISL83202IBZ
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ISL83202IBZ CAD Model

Description

The ISL83202IBZ is a half-bridge N-Channel MOSFET gate driver designed for independent channels.

  • Drivers: Four drivers
  • Package: 16-SOIC package
  • Logic Voltage: 1V to 2.5V
  • High-Side Voltage: 70V
  • Supplier: Intersil
  • Popularity Rating: Medium
  • Supply Voltage Range: 8.5V to 15V
  • Operating Temperature Range: -55°C to 150°C
