Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Intersil
Packaging Tube/Rail
Status Active
Driven Configuration Half-Bridge
Channel Type Independent
Number of Drivers 4
Gate Type N-Channel MOSFET
Supply Voltage - Operating 8.5 V to 15 V
Logic Voltage - VIL, VIH 1V, 2.5V
Current - Peak Output (Source, Sink) 1.4A, 1.3A
Input Type Non-Inverting
High Side Voltage - Max (Bootstrap) 95V
Rise and Fall Time 9ns, 9ns
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 16-SOIC
Win Source Part Number 089102-HIP4082IBZ
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Power Management, Automotive, Motor Drive & Control
Ultra Librarian 3D Model Ultra Librarian HIP4082IBZ CAD Model

Description

This Intersil integrated circuit component is a high side N-channel MOSFET driver with four independent channels and a driven configuration of half-bridge.

  • Configuration: Half-bridge
  • Channels: Four independent
  • Driver Type: High side N-channel MOSFET
  • Current Peak Output: 1.4A and 1.3A
  • High Side Voltage: 95V
  • Temperature Range: -55°C to 150°C
  • Applications: Power management, automotive, and motor drive and control
  • Popularity: High
  • Supply and Demand Status: Balanced
