10M16SAE144I7G Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Embedded - FPGAs (Field Programmable Gate Array)
Mfr Intel
Series MAX® 10
Package Tray
Product Status Active
Programmable Not Verified
Number of LABs/CLBs 1000
Number of Logic Elements/Cells 16000
Total RAM Bits 562176
Number of I/O 101
Voltage - Supply 2.85V ~ 3.465V
Mounting Type Surface Mount
Temperature Range - Operating -40°C ~ 100°C (TJ)
Package / Case 144-LQFP Exposed Pad
Supplier Device Package 144-EQFP (20x20)
Standard Package 60 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN 3A991D
HTSUS 8542.39.0001
Win Source Part Number 846775-10M16SAE144I7G
Ultra Librarian 3D Model Ultra Librarian 10M16SAE144I7G CAD Model

Description

The Intel 846775-10M16SAE144I7G is an embedded FPGA (Field Programmable Gate Array) from the MAX 10 series.

  • Series: MAX 10
  • Type: FPGA (Field Programmable Gate Array)
  • Application: Embedded Applications
  • LABs/CLBs: 1,000
  • Logic Elements/Cells: 16,000
  • Total RAM Bits: 562,176
  • Voltage Supply: 2.85V to 3.465V
  • Mounting Type: Surface Mount
  • Package/Case Size: 144-LQFP Exposed Pad
  • Supplier Device Package: 144-EQFP (20x20)
  • Operating Temperature: -40°C to 100°C
  • HTSUS Code: 8542.39.0001
  • Manufacturer: Intel
  • Status: Active
