Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Integrated Circuits (ICs)>Embedded>FPGAs (Field Programmable Gate Array)
Manufacturer Intel
Packaging Tray
Number of LABs/CLBs 3491
Number of Logic Elements/Cells 55856
Total RAM Bits 2396160
Number of I/O 321
Voltage - Supply 1.2V
Mounting Surface Mount
Temperature Range - Operating 0°C ~ 85°C (TJ)
Case / Package 484-BGA
Supplier Device Package 484-FBGA (23x23)
RoHS Status RoHS Compliant
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN 3A991D
HTSUS 8542.39.0001
Other Part Number 973653
Standard Package 84
Win Source Part Number 1323200-10CL055YU484C8G
Ultra Librarian 3D Model Ultra Librarian 10CL055YU484C8G CAD Model

Description

The Intel integrated circuit with Win Source Part Number 1323200-10CL055YU484C8G is a field programmable gate array (FPGA) that is surface mounted and has a standard package of 84.

  • I/Os: 321
  • LABs/CLBs: 3491
  • Logic Elements/Cells: 55856
  • RAM bits: 2396160
  • Voltage Supply: 1.2V
  • Supplier Device Package: 484-FBGA (23x23)
  • Temperature Range: 0°C to 85°C (TJ)
  • ECCN: 3A991D
  • RoHS Compliance: Compliant
