Products specifications Report Issue?

Reference Date Code 15+
Reference case SOP8
Manufacturer Infineon Technologies
Manufacturer Homepage www.infineon.com
Win Source Part Number 716692-TLE5012BE1000
Family Name TLE5012B
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian TLE5012BE1000 CAD Model

Description

The Infineon TLE5012BE1000 is a high-precision magnetic angle sensor designed for automotive and industrial applications. It uses an integrated magnetoresistive (xMR) sensor to detect the angle of a rotating magnetic field. This sensor provides accurate and reliable angle measurements, making it suitable for safety-critical applications.

Applications

  • Automotive steering angle sensors
  • Electric motor control
  • Robotics
  • Industrial automation
  • Angle measurement in harsh environments

Features

  • 360° angle measurement
  • High accuracy
  • Robust against magnetic stray fields
  • Differential measurement principle
  • Digital SPI interface
  • Overvoltage and reverse polarity protection
  • Automotive qualified (AEC-Q100)

Benefits

  • High Precision: Delivers accurate and reliable angle measurements, ensuring precise control and feedback.
  • Robustness: Operates reliably in harsh environments with magnetic interference.
  • Safety: Suitable for safety-critical applications with built-in protection features.
  • Easy Integration: Simplified system integration due to digital SPI interface.
  • Automotive Qualified: Meets stringent automotive industry standards for reliability and performance.

Additional Details

The TLE5012BE1000 utilizes Infineon's advanced xMR technology to provide precise angle measurements without physical contact. Its differential measurement principle enhances robustness against external magnetic fields. The integrated overvoltage and reverse polarity protection features ensure safe operation in automotive and industrial environments. This sensor is commonly used in steering angle sensors, electric motor control, and robotics applications where accurate and reliable angle measurement is critical. The digital SPI interface allows for easy communication with microcontrollers and other system components. The sensor's automotive qualification (AEC-Q100) ensures high quality and reliability under extreme operating conditions.
