TDA5255 Infineon Technologies TDA5255 real image TDA5255 label picture
Same model may have multiple batches, images only for reference.
TDA5255 Infineon Technologies TDA5255 real image TDA5255 label picture
TDA5255 Infineon Technologies TDA5255 real image TDA5255 label picture
Same model may have multiple batches, images only for reference.

TDA5255

Part No TDA5255
Manufacturer Infineon Technologies
Catalog RF Transceiver ICs
Description IC RF TXRX ISM
Datasheet
TDA5255 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Obsolete(EOL)
Type TxRx Only
RF Family/Standard General ISM
Modulation ASK, FSK
Frequency 434MHz
Data Rate (Max) 100kbps
Power - Output 13dBm
Sensitivity -109dBm
Serial Interfaces I2C, SPI
Supply Voltage - Operating 2.1 V to 5.5 V
Current - Receiving 8.6mA to 9.5mA
Current - Transmitting 5.2mA to 17.4mA
Temperature Range - Operating -40°C to 85°C
Dimension 38-TFSOP (0.173", 4.40mm Width)
Win Source Part Number 088293-TDA5255
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TDA5255 CAD Model

Description

The Infineon Technologies 088293-TDA5255 is a TxRx Only electronic component that operates at a frequency of 434MHz.

  • Family / Standard: General ISM RF
  • Modulation: ASK, FSK
  • Serial Interfaces: I2C, SPI
  • Data Rate (Max): 100kbps
  • Power Output: 13dBm
  • Sensitivity: -109dBm
  • Receiving Current: 8.6mA to 9.5mA
  • Transmitting Current: 5.2mA to 17.4mA
  • Temperature Range: -40°C to 85°C
  • Operating Voltage: 2.1V to 5.5V
