Same model may have multiple batches, images only for reference.

IRG4PC50KD

Name: IRG4PC50KD
Brand: Infineon Technologies
SKU: 161194
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	IRG4PC50KD
Manufacturer	Infineon Technologies
Catalog	IGBTs - Single
Description	IGBT 600V 52A 200W TO247AC
Datasheet	IRG4PC50KD Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Bulk
Status	Active
VCEO Maximum Collector-Emitter Breakdown Voltage	600V
Maximum Current Collector	52A
Pulsed Collector Current	104A
Collector-emitter saturation voltage(Max)	2.2V @ 15V, 30A
Maximum Power Dissipation	200W
Total Switching Energy(Ets)	1.61mJ (on), 840μJ (off)
Input Type	Standard
Gate Charge	200nC
Turn-on and Turn-off delay time	63ns/150ns
Testing Conditions	480V, 30A, 5 Ohm, 15V
Reverse Recovery Time (trr)	50ns
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	Through Hole
Case / Package	TO-247AC
Win Source Part Number	205430-IRG4PC50KD
Popularity	Medium
Supply and Demand Status	Limited
Ultra Librarian 3D Model	Ultra Librarian IRG4PC50KD CAD Model

Description

The Infineon Technologies IRG4PC50KD is a TO-247AC packaged IGBT transistor with a VCEO maximum collector-emitter breakdown voltage of 600V and a maximum current collector of 52A.

Maximum Power Dissipation: 200W
Gate Charge: 200nC
Reverse Recovery Time (trr): 50ns
Input Type: Standard
Operating Temperature: -55°C to 150°C (TJ)
Collector-Emitter Saturation Voltage (Max): 2.2V @ 15V, 30A
Total Switching Energy (Ets): 1.61mJ (on), 840μJ (off)
Turn-On and Turn-Off Delay Time: 63ns/150ns
Supply and Demand Status: Limited
