IRG4BH20K-S Real Image IRG4BH20K-S Real Image1 IRG4BH20K-S Real Image2
Same model may have multiple batches, images only for reference.
IRG4BH20K-S Real Image IRG4BH20K-S Real Image1 IRG4BH20K-S Real Image2
IRG4BH20K-S Real Image IRG4BH20K-S Real Image1 IRG4BH20K-S Real Image2
Same model may have multiple batches, images only for reference.

IRG4BH20K-S

Part No IRG4BH20K-S
Manufacturer Infineon Technologies
Catalog IGBTs - Single
Description IGBT 1200V 11A 60W D2PAK
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Features IGBT - 1200 V 11 A 60 W Surface Mount D2PAK
Manufacturer Infineon Technologies
Package Tube
Part Status Obsolete
Operating Temperature Range -55°C ~ 150°C (TJ)
Mounting Surface Mount
Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Case / Package D2PAK
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Quantity per package 50
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 875203-IRG4BH20K-S
Ultra Librarian 3D Model Ultra Librarian IRG4BH20K-S CAD Model

Description

The Infineon Technologies IGBT - 1200 V 11 A 60 W Surface Mount D2PAK is a high-performance electronic component that is designed for use in various applications.

  • Package: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
  • Operating Temperature Range: -55°C ~ 150°C (TJ)
  • Category: Discrete Semiconductor Products
  • Case/Package: D2PAK
  • Product Status: Obsolete
  • Supply and Demand Status: Limited
